Description
Highlights
- Mono subwoofer amplifier.
- 1,200 watts RMS x 1 (rated power from 1.5 to 4 ohms).
- Variable high- and low-pass filter (50-500 Hz 12 or 24dB/octave).
- Switchable subsonic filter (30 Hz) and output polarity control.
- Removable power and speaker plugs.
- Optional wired remote for level control.
- Optional HD stacking kit for stacking multiple HD amps together.
- Single Cycle Control Class D amplifier design.
- Regulated, Intelligent Power Supply System (RIPS) ensures consistent power output over a wide range of battery voltages and load impedances.
- Differential-balanced inputs eliminate noise from your vehicle's electrical system.
- Speaker- and preamp-level inputs (speaker-level input requires an optional adapter).
- Preamp outputs.
- 4-gauge power and ground leads and a 100-amp fuse recommended — wiring and hardware not included with amplifier.
- No onboard fuses — when installing multiple amps in a system, an additional 100-amp in-line fuse between the distribution block and the amplifier is recommended.
- 10-13/16"W x 2"H x 8-13/16"D
- warranty: 2 years
Features
| Amplifier Class | D |
| Low-Pass Crossover Frequency | 50 - 500 Hz |
| Low-Pass Slope (dB / octave) | 12 or 24 dB / oct |
| High-Pass Crossover Frequency | 50 -500 Hz |
| High-Pass Slope (dB / octave) | 12 or 24 dB / oct |
| Fuse Rating | 100 |
| Preamp Outputs | 2 |
| Width | 10 ¹³⁄₁₆ " |
| Height | 2" |
| Depth | 8 ¹³⁄₁₆" |
Specifications
| RMS Power Output | 1200 x 1 |
| Power at 2-Ohms | 1200 x 1 |
| Minimum Impedance Unbridged | 1.5 |
| Minimum Impedance | 1.5 |
| Best Frequency Response | 6-8k Hz |
| THD at Rated RMS Power | 0.03% |
| Signal to Noise Ratio | 82 dB |
| Input Voltage | 14.4v |
