Availability: 1 In Stock
  • Peak Power : 160W
  • RMS Power : 40W
  • Sensitivity : 87dB/ W at 1 m
  • Frequency Response : 76Hz - 21,000Hz


  • Woofer Size: 5-1/4 in (130mm)
  • Woofer Diaphragm: Injection PP cone


  • Tweeter Size: 1 in (25mm)
  • Tweeter Diaphragm: Soft Dome

Dimensions (without grill)

  • Width: 5-3/16 in (132mm)
  • Height: 5-3/16 in (132mm)
  • Depth: 2-15/16 in (75mm)
  • Mounting Depth: 2-3/8 in (60mm)
Model Name KFC-X134
System 2way-speaker
Power Handling KITS Spec
Peak Input Power 160W
Maximum Input Power 70W
Rated Power 35W
CTA Spec (CTA-2031 Compliant)
RMS Power 40Watts RMS
Sensitivity 87dB/ W at 1 m
Frequency Response 76 Hz~21,000 Hz
Woofer Diaphragm P.P. Cone Gray
Size Oversized 130 mm 5-1/4 inch
Surround Rubber
Basket Steel
Magnet Ferrite φ80 x t13
Tweeter Diaphragm Soft Dome
Size 25 mm 1 inch
Magnet Nd Up to Engineer
Dimension Woofer
with Grille
Width 160.0 mm 6-5/16 inch
Height 160.0 mm 6-5/16 inch
Depth 81.5 mm 3-3/16 inch
without Grille
Width 132.0 mm 5-3/16 inch
Height 132.0 mm 5-3/16 inch
Depth 74 mm 2-15/16 inch
Cut-out Diameter 120.0 mm 4-3/4 inch
Tweeter Height 14 mm 9/16 inch
Mounting Depth 60.0 mm 2-3/8 inch
Accessory Grille 2 pcs
Grille Holder
Punching Net
Tweeter with Woofer Frame -6dB/oct
Screw sets
Binding Head Tapping Screw φ4 x 25 mm 8 pcs
Speed Nut φ4 8 pcs
Speaker Cord 0.3 m 1 set
Adhesive Tape 1 set
