Availability: Back-ordered - Reserve yours today! By clicking add to cart you understand that this product will ship when available.

Peak Power : 300W

RMS Power : 130W

Sensitivity : 89dB/ W at 1 m

Frequency Response : 51Hz - 20,000Hz

  • Woofer
    • Woofer Size: 6 x 9 in (153 x 229mm)
    • Woofer Diaphragm: Injection PP cone
  • Tweeter
    • Tweeter Size: 1-3/16 in (30mm)
    • Tweeter Diaphragm: Soft Dome
  • Dimensions (without grill)
    • Width: 9-5/16 in (236.4mm)
    • Height: 6-7/16 in (164mm)
    • Depth: 4-1/8 in (104.5mm)
    • Mounting Depth: 3-3/8 in (85mm)
Model Name KFC-X694
System 2way-2speaker
Power Handling KITS Spec
Peak Input Power 300W
Maximum Input Power 110W
Rated Power 55W
CTA Spec (CTA-2031 Compliant)
RMS Power 130Watts RMS
Sensitivity 89dB/ W at 1 m
Frequency Response 51 Hz~20,000 Hz
Woofer Diaphragm P.P. Cone Gray
Size 153x229 mm 6x9 inch
Surround Rubber
Basket Steel
Magnet Ferrite φ100 x t17
Tweeter Diaphragm Soft Dome
Size 30 mm 1-3/16 inch
Magnet Nd Up to Engineer
Dimension Woofer
with Grille
Width 266.4mm 10-1/2 inch
Height 193.4mm 7-5/8 inch
Depth 113.5 mm 4-7/16 inch
without Grille
Width 236.4 mm 9-5/16 inch
Height 164 mm 6-7/16 inch
Depth 104.5 mm 4-1/8 inch
Cut-out Diameter 218.0 x 149.0 mm 8-9/16 x 5-7/8 inch
Tweeter Height 19.5 mm 3/4 inch
Mounting Depth 85.0 mm 3-3/8 inch
Accessory Grille 2 pcs
Grille Holder
Punching Net
Tweeter with Woofer Frame -6dB/oct
Screw sets
Binding Head Tapping Screw φ4 x 40 mm 8 pcs
Hexagon Head Bolt M4 x 70 mm 8 pcs
Hexagon Nut M4 8 pcs
Flat Washer M4 8 pcs
Flat Washer φ4 8 pcs
Spring Washer φ4 8 pcs
Speaker Cord 0.3 m 1 set
Adhesive Tape 1 set
