Highlights
Dual Camera package is equipped with 3.7 Megapixel* Wide Quad Hi-Vision (Front Camera) and 2.0 Megapixel High-Vision (Rear Camera) recording and provides easy data transfer to your smartphone through Wireless Link.
*In Dual Camera Mode, both cameras maximum recording resolution is 2.0 Megapixel. Rear cam must be turned off in menu setting to enable front cam 3.7 Megapixel recording.

Features
- Wide Quad HD Recording 2560 x 1440, 3" LCD, Built-in Wi-Fi
- Rear Camera (1080), G-Sensor
- HDR, GPS, 16GB micro SD
- 12V Plug
- Suction cup & 3M installation bracket included
Video Recording

The DRV-A501WDP includes 2 dash cams: 1 to record in front of your vehicle and 1 to record behind your vehicle, all at the same time. The rear dash cam includes a 26’ cable that connects to the front dash cam, allowing it to easily be mounted to the rear windshield or anywhere else in the vehicle where you would like to record. When in Dual Camera Recording Mode, both cameras maximum recording resolution is 2.0 Megapixel (Full HD). Rear cam must be turned off in menu setting to enable front cam 3.7 Megapixel recording.

Polarized Filter Included (Front Camera) Simply attach PL filter to front of lens to reduce windscreen glare/reflection. The filter has a rotating bezel, so that you can setup the reflection free lens exactly how you need in your vehicle.
3.7 & 2.0 Megapixel Recording provides High Resolution Recording 3.7 & 2.0 Megapixel High Definition recording captures clear video even while driving.
HDR (High Dynamic Range) & WDR (Wide Dynamic Range) for Backlighting Easily records clear images in dark or well lit settings without underexposing or overexposing the image.

Without HDR/WDR

With HDR/WDR
Front camera switches to WDR when rear camera is connected
Smartphone Features
Access Your Dash Cam Data Wirelessly KENWOOD Dash Cam Manager App Icon Wireless Link App Easily share recorded videos directly to social media using the KENWOOD DASH CAM MANAGER smartphone application (iOS 9.0+ or Android 5.0.2+)
Navigation Features
G-sensor & Built-in GPS The DRV-A501W is equipped with a G-Sensor designed to detect a collision, and GPS that records speed, latitude, and longitude.
Specifications
Storage
- 16GB microSD Included
- Supports micro SDXC/SDHC MicroSDXCME 8GB to 256GB
- SD Card Recorded File Capacity 8GB Micro SD = 47 mins (1 minute x 47 recordings) 16GB Micro SD = 94 mins (1 minute x 94 recordings) 32GB Micro SD = 141 mins (1 minute x 141 recordings) 64GB Micro SD = 376 mins (1 minute x 376 recordings) 128GB Micro SD = 752 mins (1 minute x 752 recordings) 256GB Micro SD = 1504 mins (1 minute x 1504 recordings)
*Based on default recording settings. When the vehicle is parked and turned off, parking mode becomes active. If the vehicle is subject to a collision or other physical impact, the cameras power on and automatically record 30 seconds of video.
Mounting
Magnetic Mount: Quickly place and remove the dash cam. No cable to connect or disconnect from the dash cam.
2 Mounts Included for Front Camera: 3M Tape and Suction Cup Style


Adjustable Rear Camera mounting holder enables viewing position change by up to 180 degrees.

Software
The KENWOOD VIDEO PLAYER is a desktop software for displaying video recorded with this device. Simply download the installer from https://www.kenwood.com/cs/ce/, then install according to the on-screen instructions.
Power
26'(8m) Rear Camera Cable 26' (8m) power & video cable enable you to install the rear camera inside your car, truck, or RV. Cameras work with both 12V and 24V applications.
Super Capacitor If power is lost, this prevents the recorded video file from being corrupted, as it provides enough power to allow the video file to close properly.
Measurement
Width |
4.19 (in.) |
Length |
2 (in.) |
Height |
1.5 (in.) |
